Want to improve the combustion efficiency and reduce the size and weight of steam convection ovens?

A blower with high airflow and high static pressure that makes product development more competitive

Industrial Kitchen Equipment Manufacturer Company D (100 Employees)
  • Home
  • Case Study
  • Case Study 106 - Industrial Kitchen Equipment Manufacturer Company D (100 Employees)
  • Wanted to improve the combustion efficiency of their oven.
  • Wanted to further reduce the size and weight of their oven by replacing the fan.
Solution and Results
  • Increase combustion efficiency with the PWM control function.
  • High airflow and high static pressure even in a small size.
  • Smooth verification with in-depth support.
In recent years, a number of cooking appliances that allow easy flame adjustment, cooking temperature adjustment, and cooking time management have been developed for the food service industry, and cooking automation has progressed greatly. In response to demand to provide more dishes at a lower cost, the development of new kitchen equipment and systems that are compact, provide high heat, and reduce cooking time has contributed to Japan's rich food culture.


Wanted to improve the combustion efficiency and reduce the size and weight of steam convection ovens

Company D produces a large range of commercial kitchen equipment, focusing on heating equipment. When a competitor launched a new model of steam convection oven, the company tested it against their own product. Mr. E of the Engineering Department shares with us the results:
"We compared it against our upcoming flagship model, which was then in development, but we found that unfortunately the combustion efficiency of our own model was inferior. Therefore, the Engineering Department felt it necessary to review the internals and consider a new unique structure to develop an oven that would be competitive."

Company D focused their efforts on developing the new model, but immediately faced challenges. "The fan used for the combustion mechanism of our current model was custom-made. When we contacted the supplier that had been entrusted with production in the past, they replied that it was difficult to continue production, so we decided to consider replacing the fan. During development, we reviewed the internal structure, and also set a goal for miniaturization and weight reduction," explained Mr. E.

Solution and Results

High airflow and high static pressure even in a small size

Company D tried to select a fan for the development of the new model, but it was difficult to find a fan that met their conditions.
In such a situation Mr. E visited an exhibition, where he stopped by the SANYO DENKI booth and discussed his problems with a sales representative. The SANYO DENKI representative listened carefully to Mr. E's problems, and proposed their San Ace Blower.

"We had been looking at a variety of fans, trying to find one that had the same performance as our current fan, and that would let us miniaturize and reduce the weight of our product. The 9BM type Blower proposed by the SANYO DENKI sales representative had high airflow and static pressure, and the size was just right, so I felt that it could help us reduce size and weight. Also, problems such as heat resistance could be overcome by revising the oven's internal structure, so we would be able to install a resin fan," said Mr. E.

In-depth support for a smooth verification process. Increase combustion efficiency with the PWM control function!

Soon after, Company D made a prototype containing a SANYO DENKI San Ace Blower. They achieved their initial target, a combustion efficiency improvement, and also made the oven smaller and lighter.
"The PWM control function of the proposed blower was also a key factor. We expected that we could use this to improve the combustion efficiency by adjusting the airflow. To tell the truth, I had never worked a DC fan before, and my understanding of PWM control circuits was lacking. But I consulted SANYO DENKI many times and with their advice we succeeded in making the PWM control circuit in-house," exclaimed Mr. E.

Following internal verification, Company D decided to use the San Ace Blower.
"This time, by making a bold revision to the internal structure, we developed a steam convection oven that can stand against the competition. I am very grateful to SANYO DENKI for their speedy service, from making a proposal to technical support. Looking forward, we plan to continue installing the same type of blower in other models to increase the competitiveness of our products," said Mr. E.
